Obstacle-Avoiding Smart Wheelchair System Using Arduino: Complete FYP Build Guide

Why Panels Respond Well to Assistive Tech Projects

Malaysia's population is ageing, and manual wheelchair users navigating crowded shopping malls, hospital corridors, or uneven kerbs are a problem every panel member has actually seen in person. You don't need to manufacture a justification — the problem statement writes itself, and it's the kind of topic that reads as socially useful rather than "another IoT box that blinks."

Technically, this build sits in a sweet spot: it combines distance sensing, real-time decision logic, and (depending on scope) motor control — enough breadth to fill a proper methodology chapter without needing exotic components.

Hardware Components

Component	Purpose	Cost (RM)
Arduino Uno (or compatible clone)	Main controller reading sensors and driving alerts	RM 15–40 (clone) / RM 60–120 (genuine)
HC-SR04 Ultrasonic Sensor ×3	Front and side obstacle distance detection	RM 5–8 each
Buzzer	Audible proximity warning	RM 2–4
Vibration Motor (small DC coin motor)	Optional haptic alert on the armrest	RM 3–6
L298N Motor Driver Module	Only needed if you're adding automatic speed-limiting on the wheel motors	RM 8–15
LCD 16x2 with I2C backpack	Displays distance readings / status during demo	RM 12–18
Jumper wires, mounting brackets, small enclosure	Wiring and housing	RM 15–25

Total hardware cost: RM 60–130 for the sensing-and-alert version; add the motor driver and a matched geared motor (priced separately based on the wheelchair's existing motor spec, if motorised) for the automatic speed-limiting version.

Scope note: most FYP builds in this space are retrofitted onto an existing manual wheelchair frame (borrowed for testing, or a scaled-down demo chair), not a purpose-bought unit — that's the realistic and budget-appropriate approach examiners expect to see.

How It Works

1. Three HC-SR04 ultrasonic sensors mounted at the front and two front-side corners continuously measure distance to the nearest object
2. The Arduino reads all three sensors in a loop and compares each distance against a safe threshold (commonly tuned somewhere in the 30–50cm range for indoor use, but this should be calibrated experimentally for your specific chair speed and demo environment)
3. If an object crosses the threshold, the buzzer sounds and the vibration motor pulses — the closer the object, the faster the pulse rate, giving the user an intuitive sense of "how close is close"
4. If you extend to motorised speed-limiting, the L298N reduces PWM duty cycle to the drive motors proportionally as an obstacle gets closer, rather than a hard stop, which is both safer to demo and easier to justify technically
5. The LCD shows live distance readings for each sensor — useful for your demo, since the panel can watch the numbers change as you move an object toward the chair

Wiring Overview

HC-SR04 #1 (Front):

• Trig → Pin 9, Echo → Pin 10

HC-SR04 #2 (Front-left):

• Trig → Pin 11, Echo → Pin 12

HC-SR04 #3 (Front-right):

• Trig → Pin 7, Echo → Pin 8

Buzzer: Pin 6 Vibration motor: Pin 5 (PWM, via a small transistor — do not drive it directly off the digital pin) LCD (I2C): SDA → A4, SCL → A5

Core Logic (Pseudocode)

#include <NewPing.h>
#include <LiquidCrystal_I2C.h>

#define TRIG_FRONT 9
#define ECHO_FRONT 10
#define MAX_DISTANCE 200

NewPing sonarFront(TRIG_FRONT, ECHO_FRONT, MAX_DISTANCE);
LiquidCrystal_I2C lcd(0x27, 16, 2);

void loop() {
  unsigned int distFront = sonarFront.ping_cm();

  lcd.setCursor(0, 0);
  lcd.print("Front: ");
  lcd.print(distFront);
  lcd.print("cm  ");

  if (distFront > 0 && distFront < SAFE_THRESHOLD_CM) {
    int pulseSpeed = map(distFront, 0, SAFE_THRESHOLD_CM, 50, 400);
    digitalWrite(BUZZER_PIN, HIGH);
    analogWrite(VIBRATION_PIN, 200);
    delay(pulseSpeed);
    digitalWrite(BUZZER_PIN, LOW);
    analogWrite(VIBRATION_PIN, 0);
    delay(pulseSpeed);
  }
}

The NewPing library handles the HC-SR04 timing reliably and includes a built-in median filter, which matters here — a single noisy ultrasonic reading falsely triggering an alert is one of the more common demo-day embarrassments with this build.

Common Pitfalls

• Ultrasonic sensors struggle with soft or angled surfaces — a person's clothing or a glass door can scatter the echo. Mention this limitation upfront in your report rather than let the panel discover it during your demo
• Three sensors firing in rapid succession can cross-interfere (one sensor picking up another's echo). Stagger the pings with a short delay between each sensor read, or use the NewPing library's timer-based multi-sensor mode
• Mounting height matters — sensors placed too low will pick up the floor as a constant "obstacle." Test your mounting position before finalising your enclosure design

Scope by Level

For a Diploma FYP: Single front sensor, buzzer alert, LCD readout — clean and demonstrable For a Degree FYP: Add the two side sensors and vibration feedback as described above For Merit/Distinction: Add the L298N-based automatic speed-limiting, and log obstacle-encounter data over multiple test runs as a results chapter — comparing reaction distance against a fixed baseline gives you real numbers to present
