Smart Helmet Safety Monitoring System Using ESP32: Complete FYP Build Guide

Why This Is One of the Strongest Safety FYPs You Can Build

Motorcycle accident statistics are the reason this topic exists in the first place, and any Malaysian panel understands the problem statement immediately — riders can crash in areas with no witnesses nearby, and the delay before help arrives is often the difference between a manageable injury and a fatal one. You don't need to invent a justification for this project; it's sitting in the news every week.

Technically, it's also a genuinely well-rounded build: you're combining motion sensing, GPS positioning, and cellular communication in one embedded system — three subsystems that each teach you something different, which is exactly the kind of breadth that pushes a project from "pass" to "distinction."

Hardware Components

Component	Purpose	Cost (RM)
ESP32 Development Board	Main controller, handles logic and 2 UARTs	RM 20–30
MPU6050 Accelerometer/Gyroscope	Detects sudden impact and abnormal helmet motion	RM 8–15
NEO-6M GPS Module	Provides location for the alert	RM 25–40
SIM800L GSM Module	Sends SMS alert over the cellular network	RM 25–35
3.7V LiPo Battery (1000–2000mAh)	Portable power for the helmet unit	RM 15–25
TP4056 Charging Module	Safe LiPo charging/protection	RM 3–5
Push Button	Manual SOS trigger + false-alarm cancel	RM 2–3
Buzzer	Local audible warning before SMS is sent	RM 2–4
Small project enclosure	Houses electronics on the helmet shell	RM 10–15

Total hardware cost: RM 110–170 (excluding the helmet itself — most students build into a helmet they already own)

Power note: the SIM800L needs a stable 3.7–4.2V supply capable of delivering short current peaks during transmission. Powering it directly off the ESP32's 3.3V or 5V pin is a common cause of random resets — feed it from the LiPo battery directly (through the TP4056's output), not through the ESP32.

How It Works

1. The MPU6050 continuously streams acceleration and rotation data to the ESP32 over I2C
2. Software on the ESP32 watches for the signature of a crash — a sharp spike in total acceleration followed by an abrupt change in orientation. The exact threshold isn't a fixed industry number; you calibrate it yourself by testing controlled drops/impacts on padding, since it depends on where the sensor is mounted on the helmet
3. When a likely crash is detected, a buzzer sounds and a countdown starts, giving the rider a window to cancel a false alarm (e.g. helmet dropped on the floor) via the push button
4. If not cancelled, the NEO-6M's last known GPS coordinates are read and the SIM800L sends an SMS with a Google Maps link to a pre-set emergency contact number
5. The push button can also be pressed manually as a direct SOS trigger, independent of the motion detection logic

Wiring Overview

MPU6050 (I2C):

• SDA → GPIO 21
• SCL → GPIO 22
• VCC → 3.3V, GND → GND

NEO-6M GPS (Hardware UART2):

• TX → GPIO 16 (ESP32 RX2)
• RX → GPIO 17 (ESP32 TX2)

SIM800L (Hardware UART1, remapped to spare pins since UART0 handles USB and UART2 handles the GPS):

• TX → GPIO 18
• RX → GPIO 19
• Power → directly from LiPo/TP4056 output, not from ESP32

Push button: GPIO 4 (INPUT_PULLUP) Buzzer: GPIO 25

Core Logic (Pseudocode)

#include <Wire.h>
#include <MPU6050.h>
#include <TinyGPSPlus.h>

MPU6050 mpu;
TinyGPSPlus gps;
HardwareSerial sim800(1); // ESP32 UART1, remapped to GPIO 18/19

void setup() {
  sim800.begin(9600, SERIAL_8N1, 18, 19);
  Serial2.begin(9600); // GPS on hardware UART2 (GPIO16 RX2 / GPIO17 TX2)
}

void loop() {
  int16_t ax, ay, az;
  mpu.getAcceleration(&ax, &ay, &az);
  float totalAccel = sqrt(sq(ax) + sq(ay) + sq(az));

  if (totalAccel > CRASH_THRESHOLD) {
    soundBuzzer();
    if (!cancelledByButton(5000)) {  // 5-second cancel window
      String location = getGPSCoordinates();
      sendSMS(EMERGENCY_NUMBER, "Possible crash detected. Location: " + location);
    }
  }

  if (digitalRead(SOS_BUTTON) == LOW) {
    sendSMS(EMERGENCY_NUMBER, "Manual SOS: " + getGPSCoordinates());
  }
}

CRASH_THRESHOLD is something you determine experimentally and document — examiners will ask how you arrived at that number, and "we tested 20 controlled drops and found X" is a far stronger answer than a guessed figure.

Common Pitfalls

• GPS takes time to get a fix. NEO-6M can take 30 seconds to a few minutes for a cold start outdoors, and won't get a reliable fix indoors at all — plan your demo location accordingly
• False positives from normal riding. Potholes, kerbs, and sudden braking can spike acceleration too. Combining the acceleration spike with an orientation change (helmet ending up sideways/upside-down) cuts false triggers significantly
• SIM800L needs a local SIM with credit/an active plan for the SMS to actually send during your demo

Scope by Level

For a Diploma FYP: MPU6050 crash detection + buzzer alert + manual SOS button, no GPS/GSM required For a Degree FYP: Add GPS location and SMS alert as described above For Merit/Distinction: Add a companion app showing rider status, or an MQ-3 alcohol sensor as a secondary safety layer, and log incident data for a results chapter
