ESP32-Based Solar Panel Performance Monitoring System: Complete FYP Build Guide

Why This Project Has Real Staying Power

Every renewable energy push in Malaysia — NEM (Net Energy Metering), solar incentive schemes, campus solar installations — needs one unglamorous thing to actually work: knowing whether the panel is performing as expected. That's the entire premise of this project, and it's a much easier problem statement to defend than a generic "green energy is important" opener, because you're solving something a real solar installer would care about.

It's also a clean, well-scoped build. You're not fighting with unreliable sensors or fuzzy thresholds — you're measuring real electrical quantities (voltage, current, power) with an accurate sensor, logging them, and calculating efficiency against expected output. That precision is easy to defend under questioning.

Hardware Components

Component	Purpose	Cost (RM)
ESP32 Development Board	Microcontroller + WiFi for dashboard push	RM 20–30
INA219 Current/Voltage Sensor Module	High-side voltage and current measurement	RM 15–25
Small Solar Panel (6V or 12V, 5–20W)	The panel being monitored	RM 30–60
BH1750 Digital Light Sensor	Ambient light (lux) reference reading	RM 8–15
Small 12V lead-acid or LiFePO4 battery (optional)	Load for charge/discharge testing	RM 40–80
OLED Display 0.96"	Local live readout	RM 10–15

Total hardware cost: RM 85–145 (excluding the optional battery)

Important sizing note: the INA219 measures bus voltage up to 26V. Stick to a small 6V or 12V panel setup so your panel's open-circuit voltage stays comfortably within that range — don't wire a large panel directly into it.

How It Works

1. The INA219 sits in series with the solar panel's output (via its shunt resistor) and measures bus voltage and current simultaneously
2. The ESP32 reads voltage, current, and calculated power from the INA219 over I2C using the Adafruit_INA219 library
3. The BH1750 gives a simultaneous lux reading, so your results chapter can plot power output against actual light conditions rather than just time of day
4. Readings are shown locally on the OLED and pushed to a dashboard (ThingSpeak, Blynk, or a custom web app) at a regular interval
5. The system calculates instantaneous efficiency by comparing measured output power against the panel's rated capacity under the current light level, which is the kind of derived metric that shows engineering judgement, not just data logging

Wiring Overview

INA219 (I2C):

• SDA → GPIO 21, SCL → GPIO 22
• VIN+ and VIN- wired in series between the panel's positive terminal and the load/battery

BH1750 (I2C, shares the bus with INA219 — different I2C address):

• SDA → GPIO 21, SCL → GPIO 22

OLED (I2C, same bus):

• SDA → GPIO 21, SCL → GPIO 22

Core Logic (Pseudocode)

#include <Wire.h>
#include <Adafruit_INA219.h>
#include <BH1750.h>

Adafruit_INA219 ina219;
BH1750 lightMeter;

void loop() {
  float busVoltage = ina219.getBusVoltage_V();
  float current_mA = ina219.getCurrent_mA();
  float power_mW = ina219.getPower_mW();
  float lux = lightMeter.readLightLevel();

  displayOnOLED(busVoltage, current_mA, power_mW, lux);
  pushToDashboard(busVoltage, current_mA, power_mW, lux);

  delay(2000);
}

Dashboard and Results Chapter Ideas

• ThingSpeak — free, simple, good for showing days/weeks of logged power-vs-time data
• Blynk — faster to demo live with a gauge widget during your viva
• Plot power output against lux readings across a full day to show the panel's real-world performance curve — this single graph does a lot of work in your results chapter

Presentation Tips

• Demo with a desk lamp or by tilting the panel toward/away from a window — showing power output respond live to light changes is more convincing than a static number
• Be ready to explain why you chose a shunt-based sensor (INA219) over a simple voltage divider — the answer is that current measurement needs a shunt, voltage alone doesn't tell you power
• Have a few days of logged data ready; a single demo reading looks thin next to a proper dataset

Scope by Level

For a Diploma FYP: Live voltage/current/power readings on OLED + basic dashboard For a Degree FYP: Add lux correlation and calculated efficiency against rated panel capacity For Merit/Distinction: Add a small battery charge/discharge cycle test and compare charging efficiency at different light levels, or extend to multiple panels for a comparison study
