GPS Vehicle Tracking System Using GSM Module: Complete FYP Build Guide

Why Panels Like This One

Vehicle theft and fleet visibility are problems every panel member has an opinion on, which makes the pitch easy — you're not inventing a need, you're building a cheaper, transparent version of something commercial GPS trackers already do behind a monthly subscription. That "no recurring fees, just a SIM card" angle is a genuinely strong selling point for a Malaysian FYP audience that cares about cost-consciousness.

The technical spread is good too: satellite positioning, serial communication with two separate modules, and cellular messaging — three distinct subsystems that give you real content for a methodology chapter.

Hardware Components

Component	Purpose	Cost (RM)
Arduino Uno (or compatible clone)	Reads GPS data and controls the GSM module	RM 15–40 (clone) / RM 60–120 (genuine)
NEO-6M GPS Module	Acquires latitude/longitude from satellites	RM 25–40
SIM800L GSM Module	Sends location via SMS over the cellular network	RM 25–35
Prepaid SIM card (2G/GSM-capable)	Network connection for SMS	User-provided, ~RM 10–15 credit
Step-down power supply / 3.7–4.2V Li-ion cell	Dedicated power for the SIM800L	RM 15–25
1000µF capacitor	Absorbs current spikes during GSM transmission	RM 1–3
Jumper wires, enclosure	Wiring and housing	RM 10–15

Total hardware cost: RM 90–150. Malaysia hasn't announced any 2G network shutdown as of 2026 (3G was already phased out by end of 2021), so a SIM800L on a prepaid SIM is a safe bet for now — but it's worth confirming with your telco before committing your whole project to it.

How It Works

1. The NEO-6M GPS module continuously listens for satellite signals and outputs raw NMEA sentences over serial, which the TinyGPS++ library parses into usable latitude/longitude values
2. The Arduino checks GPS lock status in a loop; once a valid fix is acquired, it holds the last known coordinates in memory
3. On a trigger — either a fixed interval, or an incoming "LOCATE" SMS from the owner's phone — the Arduino sends an AT command sequence to the SIM800L, instructing it to text the current coordinates (formatted as a Google Maps link) to a preset number
4. Because GPS satellite acquisition can take anywhere from several seconds to a couple of minutes on a cold start (especially indoors or under heavy cloud cover), your report should account for this lag rather than assume instant lock every time
5. The SIM800L's SMS delivery gives you a simple, infrastructure-free reporting channel — no data plan, no server, no app required, which is exactly the "cheap and robust" pitch that makes this project attractive

Wiring Overview

NEO-6M GPS Module (SoftwareSerial):

• TX → Pin 10, RX → Pin 11

SIM800L GSM Module (SoftwareSerial, separate pins):

• TX → Pin 2, RX → Pin 3
• Power the SIM800L from its own regulated 3.7–4.2V supply, not the Arduino's 5V pin — its transmit bursts can pull current spikes reported to reach as high as 2A, which a USB port or the Arduino's onboard regulator cannot safely deliver

Important upload tip: the GPS module streams data continuously, which can interfere with Pin 0 (RX) during sketch uploads on some wiring configurations. If your upload fails or hangs, temporarily disconnect the GPS TX line, upload, then reconnect.

Core Logic (Pseudocode)

#include <SoftwareSerial.h>
#include <TinyGPS++.h>

SoftwareSerial gpsSerial(10, 11);
SoftwareSerial gsmSerial(2, 3);
TinyGPSPlus gps;

void sendLocationSMS() {
  gsmSerial.println("AT+CMGF=1");
  delay(200);
  gsmSerial.println("AT+CMGS=\"+60XXXXXXXXX\"");
  delay(200);
  gsmSerial.print("Location: https://maps.google.com/?q=");
  gsmSerial.print(gps.location.lat(), 6);
  gsmSerial.print(",");
  gsmSerial.print(gps.location.lng(), 6);
  gsmSerial.write(26); // Ctrl+Z sends the message
}

void loop() {
  while (gpsSerial.available() > 0) {
    gps.encode(gpsSerial.read());
  }
  if (gps.location.isValid() && triggerConditionMet()) {
    sendLocationSMS();
  }
}

Common Pitfalls

• Powering the SIM800L directly from the Arduino's 5V pin is the single most common failure in this build — the module resets or fails to register on the network mid-transmission. A dedicated supply plus the bulk capacitor across VCC/GND fixes this in almost every case
• No GPS lock indoors — always test outdoors or near a window with a clear sky view; a lab bench in the middle of a building will rarely get a fix
• Forgetting to check AT command responses — the SIM800L needs a few seconds after power-up to register on the network before it will accept SMS commands; sending commands too early silently fails

Scope by Level

For a Diploma FYP: On-demand location via incoming SMS request, single recipient number For a Degree FYP: Add periodic auto-reporting at fixed intervals, plus a basic geofence check that triggers an alert SMS if the vehicle leaves a defined radius For Merit/Distinction: Push coordinates to a simple web dashboard instead of (or alongside) SMS, and log historical routes as a results chapter comparing tracked distance against actual odometer readings
