Why This Project Keeps Getting Approved
Malaysia has close to half a million people registered with the Department of Social Welfare as having visual impairments, and most still navigate with a plain cane that tells them nothing beyond "something is touching the tip." That gap between a passive mobility tool and one that actively senses the environment is an easy, honest problem statement — you don't need to dress it up, and panels rarely push back on the social relevance.
Technically, it's a forgiving build too. You're combining distance sensing, threshold-based decision logic, and dual-mode feedback (audio plus haptic) — enough for a real methodology chapter, without needing a camera, machine learning, or anything that eats your semester in debugging.
Hardware Components
| Component | Purpose | Cost (RM) |
|---|---|---|
| Arduino Uno (or compatible clone) | Reads sensors, drives the buzzer and vibration motor | RM 15–40 (clone) / RM 60–120 (genuine) |
| HC-SR04 Ultrasonic Sensor ×2 | Front (chest-height obstacles) and lower-angled (steps, potholes) | RM 5–8 each |
| Buzzer | Audible proximity alert | RM 2–4 |
| Vibration Motor (coin type) | Haptic alert on the handle | RM 3–6 |
| 9V battery + clip (or 18650 cell + holder) | Portable power source | RM 10–20 |
| PVC pipe or existing cane body | Housing for the electronics | RM 15–30 |
| Jumper wires, small enclosure, mounting tape | Wiring and assembly | RM 10–15 |
Total hardware cost: RM 60–120. Most FYP builds retrofit the electronics onto a standard folding cane rather than manufacturing a cane from scratch — that's both the realistic approach and the one examiners expect.
How It Works
- The front-facing HC-SR04 sensor scans directly ahead at roughly chest/head height, since that's the zone a cane's tip physically can't cover
- A second sensor, angled slightly downward, catches lower obstacles a cane tip would normally find by touch — kerbs, steps, potholes — giving the user advance warning instead of a last-second bump
- The Arduino reads both sensors in a loop and compares each distance reading against a safe threshold (commonly tuned in the 60–100cm range for a walking pace, though this should be calibrated to the user's actual walking speed)
- When an object crosses the threshold, the buzzer sounds and the vibration motor pulses — the closer the object, the faster the pulse rate, so distance is communicated intuitively rather than as a flat on/off alert
- Because two independent sensors are reporting, the system can differentiate "obstacle ahead" from "drop-off below" with two distinct alert patterns, which is a detail examiners notice and appreciate
Wiring Overview
HC-SR04 #1 (Front, chest height):
- Trig → Pin 9, Echo → Pin 10
HC-SR04 #2 (Lower, angled down):
- Trig → Pin 7, Echo → Pin 8
Buzzer: Pin 6 Vibration motor: Pin 5 (PWM, driven through a small NPN transistor — do not wire it directly to the digital pin, the motor's stall current can damage the Arduino's output driver)
Core Logic (Pseudocode)
#include <NewPing.h>
#define TRIG_FRONT 9
#define ECHO_FRONT 10
#define TRIG_LOWER 7
#define ECHO_LOWER 8
#define MAX_DISTANCE 200
#define SAFE_THRESHOLD_CM 80
NewPing sonarFront(TRIG_FRONT, ECHO_FRONT, MAX_DISTANCE);
NewPing sonarLower(TRIG_LOWER, ECHO_LOWER, MAX_DISTANCE);
void loop() {
unsigned int distFront = sonarFront.ping_cm();
delay(30); // short gap so the two sensors don't cross-interfere
unsigned int distLower = sonarLower.ping_cm();
if (distFront > 0 && distFront < SAFE_THRESHOLD_CM) {
int pulseSpeed = map(distFront, 0, SAFE_THRESHOLD_CM, 60, 400);
alertPattern(pulseSpeed, 1); // one buzzer pulse per cycle = "ahead"
} else if (distLower > 0 && distLower < SAFE_THRESHOLD_CM) {
int pulseSpeed = map(distLower, 0, SAFE_THRESHOLD_CM, 60, 400);
alertPattern(pulseSpeed, 2); // two quick pulses = "drop-off/step"
}
}
The NewPing library handles HC-SR04 timing reliably and includes a built-in median filter, which matters here — a single noisy ultrasonic bounce triggering a false alert on a demo table is one of the more common embarrassments with this build.
Common Pitfalls
- Ultrasonic sensors struggle with soft, angled, or glass surfaces — a person's trousers, foliage, or a glass door panel can scatter the echo and give an inconsistent reading. State this limitation upfront in your report rather than let the panel find it during your demo
- Two sensors firing back-to-back can cross-interfere, with one sensor picking up the other's echo. A short stagger delay between pings (as in the pseudocode above) or NewPing's timer-based multi-sensor mode avoids this
- Mounting angle on the lower sensor is fiddly — too flat and it reads the ground as a constant "obstacle," too steep and it misses actual kerbs. Budget real bench time to tune this before your final demo
Scope by Level
For a Diploma FYP: Single front sensor, buzzer alert only — clean, demonstrable, and easy to defend For a Degree FYP: Add the lower sensor and vibration feedback as described above, with distinct alert patterns for each For Merit/Distinction: Add a SIM800L GSM module so the cane can send an SOS SMS with GPS location if the user stays stationary for an unusually long time (a simple fall/distress heuristic), and log obstacle-encounter frequency over multiple test walks as a results chapter
